MIC-3042A-AE |
MIC-3042AE |
MIC-3042B-AE |
MIC-3042BE |
MIC-3042C-AE |
MIC-3042CE |
| Backplane |
6U slot |
System x 1, Peripheral x 6,Switch x 1, Rear transition x 8,(80 mm, IEEE1101.11 compliant) |
System x 1, Peripheral x 6,Switch x 1, Rear transition x 8,(80 mm, IEEE1101.11 compliant) |
System x 1, Peripheral x 6,Switch x 1, Rear transition x 8,(80 mm, IEEE1101.11 compliant) |
System x 1, Peripheral x 6,Switch x 1, Rear transition x 8,(80 mm, IEEE1101.11 compliant) |
System x 1, Peripheral x 6,Switch x 1, Rear transition x 8,(80 mm, IEEE1101.11 compliant) |
System x 1, Peripheral x 6,Switch x 1, Rear transition x 8,(80 mm, IEEE1101.11 compliant) |
| Cooling |
Fan |
2 (front: 193 CFM, rear: 61.3 CFM) |
2 (front: 193 CFM, rear: 61.3 CFM) |
2 (front: 193 CFM, rear: 61.3 CFM) |
2 (front: 193 CFM, rear: 61.3 CFM) |
2 (front: 193 CFM, rear: 61.3 CFM) |
2 (front: 193 CFM, rear: 61.3 CFM) |
| Environment |
Temperature (Operating) |
0 ~ 45° C (32 ~ 113° F) |
0 ~ 45° C (32 ~ 113° F) |
0 ~ 45° C (32 ~ 113° F) |
0 ~ 45° C (32 ~ 113° F) |
0 ~ 45° C (32 ~ 113° F) |
0 ~ 45° C (32 ~ 113° F) |
| Temperature(Non-Operating) |
-20 ~ 60° C (-4 ~ -140° F) |
-20 ~ 60° C (-4 ~ -140° F) |
-20 ~ 60° C (-4 ~ -140° F) |
-20 ~ 60° C (-4 ~ -140° F) |
-20 ~ 60° C (-4 ~ -140° F) |
-20 ~ 60° C (-4 ~ -140° F) |
| Vibration (5 ~ 500 Hz) |
Operating 1.0 Grms |
Operating 1.0 Grms |
Operating 1.0 Grms |
Operating 1.0 Grms |
Operating 1.0 Grms |
Operating 1.0 Grms |
| Physical Characteristics |
Dimensions (W x H x D) |
440 x 177 x 320 mm (17.3" x 7" x 12.6") |
440 x 177 x 320 mm (17.3" x 7" x 12.6") |
440 x 177 x 320 mm (17.3" x 7" x 12.6") |
440 x 177 x 320 mm (17.3" x 7" x 12.6") |
440 x 177 x 320 mm (17.3" x 7" x 12.6") |
440 x 177 x 320 mm (17.3" x 7" x 12.6") |
| Power Supply |
AC/Input Voltage |
AC 100 ~ 240 V @ 50 ~ 60 Hz, full range |
AC 100 ~ 240 V @ 50 ~ 60 Hz, full range |
AC 100 ~ 240 V @ 50 ~ 60 Hz, full range |
AC 100 ~ 240 V @ 50 ~ 60 Hz, full range |
AC 100 ~ 240 V @ 50 ~ 60 Hz, full range |
AC 100 ~ 240 V @ 50 ~ 60 Hz, full range |
