ITA-3630-00A1E |
ITA-3630-01A1E |
| Certification |
EMC |
CE/FCC Class A, CCC, BSMI |
CE/FCC Class A, CCC, BSMI |
| Environment |
Operational Temperature |
-25 ~ 60° C |
-25 ~ 60° C |
| Ethernet |
Controller |
Intel I210-AT,10/100/1000 Mbps |
Intel I210-AT,10/100/1000 Mbps |
| Expansion Interface |
Mini PCIe |
1 x internal Mini PCIe (Full-Size) |
1 x internal Mini PCIe (Full-Size) |
| I/O |
LPT |
1 x DB26 (Front panel, option) |
1 x DB26 (Front panel, option) |
| Memory |
Technology |
DDR3 1333/1600 MHz |
DDR3 1333/1600 MHz |
| Physical Characteristics |
Dimensions (W x H x D) |
253 x 86.6 x 240 mm |
253 x 86.6 x 240 mm |
| Power Supply |
Input Range |
DC wide range 9V ~ 36V input |
DC wide range 9V ~ 36V input |
| Processor System |
BIOS |
AMI SPI 16MB |
AMI SPI 16MB |
| Storage |
HDD |
Support 2 x 2.5" HDD or 2.5" HDD+CF module |
Support 2 x 2.5" HDD or 2.5" HDD+CF module |
| WatchDog Timer |
Output |
System Reset |
System Reset |
