UTX-3115SA4P-S6A1E |
UTX-3115SA4-S6A1E |
| Processor |
CPU |
Intel ATOM E3826 |
Intel ATOM E3826 |
Intel ATOM E3826 |
| Display |
VGA |
Up to 2560 x 1600 |
Up to 2560 x 1600 |
Up to 2560 x 1600 |
| Multiple Display |
Dual |
Dual |
Dual |
| Ethernet |
Controller |
GbE1: Intel I210AT; GbE2:Realtek 8111G |
GbE1: Intel I210AT; GbE2:Realtek 8111G |
GbE1: Intel I210AT; GbE2:Realtek 8111G |
| Audio |
CODEC |
Realtek ALC892, High Definition Audio (HD) |
Realtek ALC892, High Definition Audio (HD) |
Realtek ALC892, High Definition Audio (HD) |
| I/O |
COM Port |
1x RS-232 & 1x RS-422/485 |
1x RS-232 & 1x RS-422/485 |
1x RS-232 & 1x RS-422/485 |
| Display |
LCD (TTL/LVDS/eDP) |
N/A |
N/A |
N/A |
| DDI (HDMI/DVI/DisplayPort) |
HDMI: 1920X1080P & Micro HDMI: 1920X1080P |
HDMI: 1920X1080P & Micro HDMI: 1920X1080P |
HDMI: 1920X1080P & Micro HDMI: 1920X1080P |
| Expansion |
Slots |
1 F/S miniPCIE & 1H/S miniPCIE |
1 F/S miniPCIE & 1H/S miniPCIE |
1 F/S miniPCIE & 1H/S miniPCIE |
