ACP-2000P3-00BE |
ACP-2000P4-00BE |
| Disk Drive Bay |
Slim ODD |
1 |
1 |
1 |
| 3.5" Front-Accessible |
2 |
2 |
2 |
| Cooling |
Fan |
2 (8 cm / 47 CFM each) |
2 (8 cm / 47 CFM each) |
2 (8 cm / 47 CFM each) |
| Air Filter |
Yes |
Yes |
Yes |
| Front I/O Interface |
USB |
2 |
2 |
2 |
| PS/2 |
1 |
1 |
1 |
| Miscellaneous |
LED Indicators |
Power, HDD, temperature, fan |
Power, HDD, temperature, fan |
Power, HDD, temperature, fan |
| Rear Panel |
One 9-pin D-Sub opening |
One 9-pin D-Sub opening |
One 9-pin D-Sub opening |
| Intelligent System Module |
Remote Monitoring |
CPU/System fan speed , CPU/System temperature , motherboard voltage |
CPU/System fan speed , CPU/System temperature , motherboard voltage |
CPU/System fan speed , CPU/System temperature , motherboard voltage |
| Environment |
Operational Temperature |
0 ~ 40° C (32 ~ 104° F) |
0 ~ 40° C (32 ~ 104° F) |
0 ~ 40° C (32 ~ 104° F) |
| Non-Operational Temperature |
-20 ~ 60° C (-4 ~ 140° F) |
-20 ~ 60° C (-4 ~ 140° F) |
-20 ~ 60° C (-4 ~ 140° F) |
| Operating Humidity |
10 ~ 85% @ 40° C, non-condensing |
10 ~ 85% @ 40° C, non-condensing |
10 ~ 85% @ 40° C, non-condensing |
| Non-Operating Humidity |
10 ~ 95% @ 40° C, non-condensing |
10 ~ 95% @ 40° C, non-condensing |
10 ~ 95% @ 40° C, non-condensing |
| Operating Vibration |
0.5 Grms |
0.5 Grms |
0.5 Grms |
| Non-Operating Vibration |
2 G |
2 G |
2 G |
| Operating Shock |
10G, half sine wave, 11 ms duration |
10G, half sine wave, 11 ms duration |
10G, half sine wave, 11 ms duration |
| Non-Operating Shock |
30 G |
30 G |
30 G |
| Physical Characteristics |
Dimensions (W x H x D) |
482 x 88 x 451 mm (19'' x 3.5'' x 17.8'') |
482 x 88 x 451 mm (19'' x 3.5'' x 17.8'') |
482 x 88 x 451 mm (19'' x 3.5'' x 17.8'') |
| Weight |
11.5 kg (25.3 lb) |
11.5 kg (25.3 lb) |
11.5 kg (25.3 lb) |
